SS316
Rev A1

Spider Ord Nr.: M

Accessories to be ordered separately.
SPIDER FITTING
CLASSIC
KNB Shown are not a part of the standard supply. To be ordered separately from the table below.
Tools
           18x19
D-48
F-32
F-45
ALLEN 8
Accessories
SS Allen Bolt M12
 Ord Nr. M15697
Locking Pin
 Ord Nr. M19477
B Spacer Flat P
 Details on Page 10
W Spacer Flat P
 Details on Page 10
B Spacer Round P
 Details on Page 11
W Spacer Round P
 Details on Page 12
Shims
 Details on Page 14
DGU Ring
 Ord Nr. M18662
GSC Glass Ltd.
SCT-1A
Single arm wall to glass
B Spacer Flat SS
 Details on Page 10
W Spacer Flat SS
 Details on Page 11
B Spacer Round SS
 Details on Page 12
W Spacer Round SS
 Details on Page 13
CSK Screw M8X60
 Ord Nr. M12633
RS2FBB Washer
 Ord Nr. M10138
Shims
 Details onPage 14
Fisher SLM 8N
 Ord Nr. M10075
GP SCT-1A
 Details on Page 15
WP SCT-1A
 Details on Page 15
PK SCT-1A
 Details on Page 16
10

26472

S.No

Glass Thick (GT)

KNB

H (mm)

Name

KNB Ord Nr. (KB4)

KNB Ord Nr. (KB6)

1

08-15

KB4-15/KB6-15

98

SCT-1A-KB4-15

M10090

M13209

2

16-20

KB4-20/KB6-20

103

SCT-1A-KB4-20

M18330

M26505

3

21-25

KB4-25/KB6-25

108

SCT-1A-KB4-25

M14157

M26506

4

26-30

KB4-30/KB6-30

113

SCT-1A-KB4-30

M26499

M26507

5

31-35

KB4-35/KB6-35

118

SCT-1A-KB4-35

M19873

M26508

6

36-40

KB4-40/KB6-40

123

SCT-1A-KB4-40

M17881

M26509

7

41-45

KB4-45/KB6-45

128

SCT-1A-KB4-45

M19156

M26510

7
