SS316
Rev A1
SS316
Accessories, to be ordered separately.
Accessories, to be ordered separately.
FBE SERIES
CONNECTORS
GSC Glass Ltd.
HRF5
S.No.
Item Name
Dim H
Ord Nr.
(Black)
Ord Nr.
(White)
(White)
1
HRF5-15
15
M26518
M30217
2
HRF5-25
25
M26519
M30218
3
HRF5-40
40
M26520
M30219
4
HRF5-X
On Request
- - -
- - -
Details of Holes on Glass
(Optional, to be ordered separately.)
ALLEN BOLT M8X60
Ord Nr. M11401
Ord Nr. M11401
FISHER ANCHOR SLM 8N
Ord Nr. M10075
Ord Nr. M10075
FBE3 COVER
Ord Nr. M25368
Ord Nr. M25368
Usable in : FBE3
FBE4 COVER
Ord Nr. M22736
Ord Nr. M22736
Usable in : FBE4
ALLEN 5
ALLEN 6
|
|
CSK SCREW SS
S.No
Glass Thick (mm)
H
FBE3
Ord Nr.
FBE4
Ord Nr.
1
8 to 15 mm
30
M8X30
M50193
M10X30
M50199
2
15 to 20 mm
35
M8X35
M50194
M10X35
M50200
3
20 to 25 mm
40
M8X40
M50195
M10X40
M50201
4
25 to 30 mm
45
M8X45
M50196
M10X45
M50202
5
30 to 35 mm
50
M8X50
M50197
M10X50
M50203
6
35 to 40 mm
55
M8X55
M50198
M10X55
M50204
2
